Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA

Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA

  • Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA
  • Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA
  • Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA
Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA
Detalhes do produto:
Lugar de origem: GuangDong, China
Marca: Goodyear
Certificação: ISO/TS16949:2009
Número do modelo: 3B12-304
Condições de Pagamento e Envio:
Quantidade de ordem mínima: Negociável
Preço: Negotiable
Detalhes da embalagem: caixa forte da caixa ou como a necessidade dos clientes
Tempo de entrega: 2-8 dias do trabalho
Termos de pagamento: T/T, Western Union, Paypal ou outro
Habilidade da fonte: 1000pcs/week
Contato
Descrição de produto detalhada
Material: Placa de cobertura de aço, foles de borracha Goodyear: 3B12-304
Furo do gás: 1/4NPTF Dente do parafuso: 3/8-16UNC
Distância Center do parafuso: 157,5 milímetros Diâmetro da placa de cobertura: 228,6 milímetros
Capacidade da pressão: Um Pa de 0.2-0.8 M Curso: 120~457 milímetros
Peso líquido: 7,5 quilogramas Tamanho do pacote: 33 x 33 x 22 cm
Realçar:

503 molas de ar complicadas triplas

,

Molas de ar complicadas triplicar-se SC2132

,

3B12-304

Contitech Air Spring FT 330-29 503 Triple Convoluted Air Springs For LOAD GUARD SC2132





Contitech Air Spring FT 330-29 503 refer to 3B12-304 Cross others OEM



Goodyear 3B12-304

Goodyear 3B12 304

Goodyear 3B12304

Goodyear Flexmember 578-93-3-100

Goodyear Flexmember 578 93 3 100

Goodyear Flexmember 578933100

Contitech FT 330-29 503

Contitech FT 330-29503

Contitech FT330-29 503

Conti tech FT 330-29 503

Conti tech FT 330-29503

Conti tech FT330-29 503

Contitech 64568

Conti tech 64568

Firestone: 8006;

Firestone:W01-358-8006

Firestone:W01 358 8006

Firestone:W013588006
Firestone: 8013;

Firestone:W01-358-8013

Firestone:W01 358 8013

Firestone:W013588013

Triangle spring: 4430
Triangle spring: 4503

Kangdi Technology: 64568
Suspension company: 200620
batco: 10-98006
UCF / Impex: AB-3B12-304
T.W. Distribution: AB8006
Dallas Spring: AS8006
Midland / Haldex: CS312304
Euclid / Meritor Aftermarket: E-FS8006
Euclid / Meritor Aftermarket: FS8006
Kangdi Technology: FT330-29503
Leland: SC2132



Another similar kind 3B12-305, only Air Fitting Size (in) 3/4 is not the same.





Contitech Air Spring FT 330-29 503 refer to 3B12-304 Technical parameters



Nut / Blind Nut



Top Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC

Screw Center Distance of Top Cover Plate : 157.5 mm

Bottom Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC

Screw Center Distance of Bottom Cover Plate : 157.5 mm



Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4-18NPTF

Screw Center Distance Between Gas Hole and Nut : 73 mm



Cover Plate

Top Cover Plate Diameter: 228.6 mm

Bottom Cover Plate Diameter: 228.6 mm



Rubber Bellows

Rubber Bellows MAX Diameter: 330 mm

Rubber Bellows Natural Diameter : 300 mm

The Working Stroke : MIN 120 mm to MAX 457 mm

Maximum Height : 457 mm

Minimum Height :120 mm

Stroke Height : 179mm



Bumper block / Buffer block

Without Bumper Block



Girdle Hoop / Girdle Ring

With Girdle Hoop :One Pieces of Girdle Hoop







The drawing of Goodyear Air Spring 3B12-304:



Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA 0







Goodyear® Goodyear air spring features


Goodyear® Goodyear air springs utilize the compressive elasticity of air, and are essentially different from metal springs such as leaf springs. It has excellent characteristics as a suspension spring. For example, the combined use with a control device keeps the height of the vehicle always constant or arbitrarily changed. It can also improve the vehicle's inclination by individually controlling the left and right air springs.


Modern road transportation places high demands on the comfort and efficiency of automobiles. STEMCO (Stemco) company's mission is to "make our roads safer", knowing user satisfaction, easy and comfortable user experience, is the foundation of the product, and fully consider commercial vehicles in product design The demanding requirements of trucks and customers, such as its super-buffered air springs, use the materials and design of the load to provide industry-leading vibration damping, light weight and long service life. In addition, the unparalleled comfort performance design makes the super-buffer air spring reduce driving fatigue, reduce parts wear and tear, shorten the failure time, and thus improve safety performance.



Contitech FT 330-29 503 molas de ar complicadas triplas para o PROTETOR SC2132 da CARGA 1
